Specifications

Engine

Engine	4-stroke, single cylinder
Cooling System	Air cooled
Displacement	163cc
Engine Power	5.5hp/3600rpm
Engine Torque	8 lb ft/3600rpm
Bore	2.6 in
Stroke	1.8 in
Oil Type	SAE 15W-40
Ignition	C.D.I
Starter	Electric Start with Pull Start Backup
Top Speed	12.4mph
Carburetion	Brand: JF (RX)

Battery

Battery

12V 9Ah

Drivetrain

Clutch	Automatic w/Reverse
Driveline	Chain / Driving wheel: Dual wheel drive

Suspension

Front Suspension	Dual A-arm
Rear Suspension	Double Oil Damped Shock

Brakes

Front braking system	Disc
Rear braking system	Disc

Wheels & Tires

Front Tire	145X70-6
Rear Tire	16 X8-7

Dimensions

Overall Vehicle Size (LxWxH)	58.7x38.2x48.8 in
Wheelbase	42.6 in
Seat Height	13.6 in
Ground Clearance	Min: 4.02 in
Pedals	to seat back: 30” to 35”; Pedal can also adjusted to 3” or 6” shorter.
Dimensions	Climbing ability: 12 degrees

Capacities

Fuel Capacity	1.2 gal
Cargo Capacity	300 lbs

Weights

Weight

N.W: 232 lbs

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
