Specifications

Engine

Engine Manufacturer	Brand:Kohler
Engine	Model: KT725 | Spec: 3097
Displacement	725
Engine Power	22 HP
Emissions	Series: 7000 Series
Rated Engine Speed	3,300 rpm
Air Filter	Standard Engine Manufacturer's air filter

Fuel System

Fuel Type	Gas Carbureted
Fuel System	Fuel Indicator: Translucent Visual

PTO

PTO Type

Engagement: Electromagnetic 80-ft-lb clutch

Drivetrain

Drivetrain	Hydro-Drive | Description: Two Hydro-Gear ZT-2100 hydro static transmissions with no hoses, integrated cooling fans, integrated reservoir.
Steering	Control: Hydraulically dampened twin levers adjustable both fore and aft. Also has 2-position height adjustment.

Brakes

Parking Brake

Automatic-actuated pawl brake.

Wheels & Tires

Tires, Front Specification	18 x 9.5-8 K500 | Caster: 11 x 6.0-5 smooth-tread, pneumatic.
Tires, Rear Specification	18 x 9.5-8 K500

Electric

Electrical

12 volt battery with 15-amp alternator

Operational

Operating Speed	Forward: 0–7 mph (11.3 km/h) | Reverse: 0–5.0 mph (8.0 kmph)
Top Speed	Blade: Approximately 18,500 fpm.

Chassis

Frame Type

Tractor: Unibody, riveted 10-guage steel.

Lights and Safety

Safety Features

Package: Operator Presence Controls (OPC) and drive system interlock.

Dimensions

Width	61.7 in. (157.0 cm)
Length	Blades: 3 Blades at 17.50" | 75.0 in. (191.0 cm)
Height	Cutting: 1.5" (3.8 cm) to 4.5" (11.4 cm) in 0.50" (1.3 cm) increments | 45.6 in. (113.0 cm)
Spindle Diameter	Blade Cutter Housing: 5.50" | Blade Shaft: 0.67"-
Dimensions	Casters: .25" thick caster yoke arms.
Cutting Width	Deck: 50"

Capacities

Fuel Capacity

3 gallon (11.0-L) single fuel tank with single fill locations

Weights

Weight

Curb: Approx. 415

Features

Seat Type	Units have 16" high-back (no armrests). Hinged mounting with spring suspension. Adjustment fore and aft 3" by loosening 2 bolts and sliding seat.
Construction Material, Deck	Style: Floating Deck | Style Description: Series 2 fabricated and welded steel deck. Decks have side discharge standard with the option ot bag or mulch. | 10-gauge top that is formed and welded, 12-gauge side skirt and 7-gauge welded bumper. 3 point suspension.

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
