Specifications

Engine

Engine Manufacturer	Brand: Kohler
Engine	Model: KT735 | Spec: 3089
Displacement	725
Emissions	Series: V-Twin
Rated Engine Speed	3,300 rpm
Engine Power	HP: 24.5
Air Filter	Standard Engine Manufacturer's air filter

Fuel System

Fuel System	Fuel Indicator: Translucent Visual | Carbureted
Fuel Type	Gas Carbureted

PTO

PTO Type

Engagement: Electromagnetic 105-ft-lb clutch

Drivetrain

Drivetrain	Hydro-Drive | Description: Two Hydro-Gear ZT-2200 hydro static transmissions with no hoses and integrated cooling fans and integrated reservoir
Steering	Control: Hydraulically dampened twin levers adjustable both fore and aft. Also has 2-position height adjustment.

Brakes

Parking Brake

Lever-actuated pawl brake.

Wheels & Tires

Tires, Front Specification	20 x 10.0-10 Turf Tech TL | Caster: 13 x 6.5-5 smooth-tread, pneumatic
Tires, Rear Specification	20 x 10.0-10 Turf Tech TL

Electric

Electrical

12 volt battery with 15-amp alternator

Operational

Operating Speed	Forward: 0–7 mph (11.3 km/h) | Reverse: 0–3.4 mph (5.5 km/h)
Top Speed	Blade: Approximately 18,500 fpm.

Chassis

Frame Type

Tractor: Unibody, Riveted 10 ga. Steel

Lights and Safety

Safety Features

Package: Operator Presence Controls (OPC) and drive system interlock.

Dimensions

Spindle Diameter	Blade Cutter Housing: 5.50" | Blade Shaft: 0.67"
Dimensions	Casters: .25" thick caster yoke arms.
Cutting Width	Deck: 54"
Width	65.2 in. (166.0 cm)
Length	Blades: 3 Blades at 18.75" | 76.0 in. (193.0 cm)
Height	Cutting: 1.5" (3.8 cm) to 4.5" (11.4 cm) in 0.50" (1.3 cm) increments, adjustable from operator's seat. | 46.6 in. (119.0 cm)

Capacities

Fuel Capacity

3.0-gallon (11.0-L)

Weights

Weight

Curb: Approx. 616

Features

Seat Type	Commercial grade, high back contoured foam padded with arm rests. Hinged mounting and spring suspension. Adjustment is fore and aft for operator position.
Construction Material, Deck	Style: Floating | Style Description: Series 2 fabricated and welded steel deck. Decks have side discharge standard with the option ot bag or mulch. | 10-gauge top that is formed and welded, 12-gauge side skirt and 7-gauge welded bumper. 4 point suspension.

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
