Specifications

Engine

Engine Manufacturer	Brand: Kawasaki
Displacement	726
Emissions	Series: V-Twin
Rated Engine Speed	3,800 rpm
Air Filter	Cyclonic Air Cleaner

Fuel System

Fuel Type	Gas Carbureted
Fuel System	Fuel Indicator: Translucent Visual

PTO

PTO Type

Engagement: MagStop electromagnetic 125-ft-lb clutch

Drivetrain

Drivetrain	Hydro-Drive | Description: Dual Hydro Gear ZT3100, hydrostatic transmission with charge pumps, relief valves and independent, replaceable filters.
Steering	Control: Hydraulically dampened twin levers adjustable both fore and aft. Also has 2-position height adjustment.

Brakes

Parking Brake

Lever-actuated pawl brake.

Wheels & Tires

Tires, Front Specification

23 x 9.5-12 Super Turf TL | Caster: 13 x 6.5-6, smooth tread, pneumatic. Caged Roller Bearings (126-3289)

Electric

Electrical

12-volt battery with 15-amp alternator.

Operational

Operating Speed	Forward: 0–9.0 mph (14.5 kmph) forward, 0–5.0 mph (8.0 kmph) reverse.
Top Speed	Blade: Approximately 18,500 fpm.

Chassis

Frame Type

Tractor: Unibody, welded, heavy-duty 2" X 3" rectangular tubular steel.

Lights and Safety

Safety Features

Package: Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.

Dimensions

Spindle Diameter	Blade Cutter Housing: 7.30" | Blade Shaft: 17mm (.67")
Dimensions	Casters: .375" thick caster yoke arms
Cutting Width	Deck: 52"
Length	Blades: 3 Blades at 18.00" | 80.3in (204.0 cm)
Width	64.3 in (163.3 cm)
Height	Cutting: 1.5" (3.8 cm) to 5.0" (12.7 cm) in 0.25" (.6 cm) increments | 69.7 in (177.0 cm)

Capacities

Fuel Capacity

7-gallon (26.5-L)

Weights

Weight

Curb: 923

Features

Seat Type	Deluxe suspension (adjustable spring suspension) seat with high back, molded foam flip-up armrests, and integral safety switch
Construction Material, Deck	Style: Floating | Style Description: Full-floating UltraCut Series 3. Side discharge standard, with molded discharge chute and option to bag or mulch. | 10-gauge high strength alloy top that is formed and continuously seam welded, with 7-gauge side skirt.

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
